Ubiquiti 48 Port Gigabit 195W 32PoE 4SFP UniFi Switch

Ubiquiti’s USW-48P is a managed Layer 2 switch with 48x Gigabit Ports. It includes 32x 802.3at PoE+ ports, 4x 1.25Gbps SFP uplink ports and a PoE budget of 195W. The unit features a 1.3″ touch LCM to provide status information.

It can be configured and managed with the UniFi Network Application.

• Overview
• Dimensions: 442 x 285 x 44 mm (17.4 x 11.2 x 1.7″)
• Port Layout: 1 GbE RJ45: 48 (32 PoE+)
• 1G SFP: 4
• Max. PoE Output: Up to PoE+
• Total PoE Availability: 195W
• Form Factor: Rack mount (1U)
• Performance
• Switching Capacity: 104 Gbps
• Total Non-Blocking Throughput: 52 Gbps
• Forwarding Rate: 77 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 16,000
• Packet Buffer Size: 1.5 MB
• Layer 2 Features
• LACP Port Aggregation: Yes
• STP & RSTP: Yes
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
• IGMP Snooping: Yes
• 802.1X Control: Yes
• MAC-Based ACLs & Device Isolation: Yes
• DHCP Snooping & Guarding: Yes
• Egress Rate Limit: Yes
• Flow Control: Yes
• Storm Control: Yes
• Multicast & Broadcast Rate Limiting: Yes
• MAC Address Blocking: Yes
• IP-Based ACLs & Network Isolation: Yes
• MAC-Based Port Restriction: Yes
• Port Isolation: Yes
• Port Mirroring: Yes
• Jumbo Frames: Yes
• LLDP-MED: Yes
• Voice VLAN: Yes
• Loop Protection: Yes
• Hardware
• PoE Ports
• PoE+: 32
• Max. PoE Wattage per Port by PSE
• PoE: 15.4W
• PoE+: 32W
• Max. Power Consumption: 45W (Excluding PoE Output) 240W (Including PoE Output)
• Power Method: Universal input, 100—240V AC, 50/60 Hz
• Power Input Method: AC input
• Power Supply: AC/DC, internal, 240W
• Supported Voltage Range: 100—240V AC
• Management: Ethernet AR
• Heat Dissipation (Excluding PoE Output): 153.54 BTU/hr
